1.Machine tool control system uses Taiwan system. Other company’s numeral control system can also be used when user requires so
2.Machine body is cast in one piece with resin bonded sand, so it features strong vibration resistance and less deformation. The lathe bed tilts by 45°and the inclined placement of lathe carriage and tool holder will result in easy operation and chip removal. The machine tool has pleasant design appearance and less space occupation
3.Taiwan’s high-precision spindle, comprising Japan NSK precise bearings; φ160 three-jaw hydraulic chuck or other elastic clamp can be directly fitted on the main shaft flange
4.The drive part of machine tool uses HIWIN/PMI high precision P3 class ball bearing screw and high speed linear slide rail, a famous brand from Taiwan and is provided with computer automatic lubrication system for forced lubrication of linear guide rail and ball bearing screw. For X axis and Z axis, high rigidity linear slide rail is adopted with optimum span between rails through calculation. With low resistance, high rigidity and high precision, the displacement speed can reach up to 30M/min so as to improve working efficiency and reduce processing time
5.Full-closed protection and Exterior Design is graceful and decent. Waterproof properties is better; Independent water tank, so it is convenient to maintain the daily cleaning
6.Spindle motor adopts AC servo motor, other optional
7.Workpiece clamping type: Hydraulic
8.Machine tool hydraulic supply unit, tank volume increase, better heat dissipation effect, work more stable
9.Equipped with computer automatic lubrication system for the linear guide and ball screw forced lubrication, ensure that the guide rail and the service life of screw
10.The machine of cnc automatic lathe machine can be customized make in Guoqiang.
Model | DS-5E |
Max.swing diameter(mm) | 380 |
Max.processing length(mm) | 250 |
Chuck size(inch) | 5″ |
Spindle speed(r/min) | 1-4500 |
Spindle power(kw) | 5.5 |
Spindle bore(mm) | Ф46 |
Center high(mm) | 56 |
X/Z axis travel(mm) | 1040/270 |
X/Z axis fast moving speed(r/min) | 30 |
X/Z axis repeatability(mm) | ±0.003 |
Cutter install way | gang type+power head |
Square knife tool apron(mm) | 20×20 |
Circular hole tool apron(mm) | Ф20 |
X/Z axis motor power(kw) | 1.3 |
Power head structure | 1with 2 gear (double short axis) |
Power head motor power(kw) | Standard 1.3(optional 1.8) |
Power head speed(r/min) | 0-4500 |
Bar feeder ground to center(mm) | 1120 |
Machine power(kw) | 10 |
Net weight(kg) | 2800 |
Machine dimensions(L×W×H)(mm) | 2250×1500×1950 |
