1.Machine tool bed is casting with resin sand, its features strong vibration resistance and difficult deformation
2.Yaskawa servo drive is used for main spindle motor.Ensuring the high precision requirement of multiple thread screw
3.The main shaft contains high precision Japan NSK precise bearing with the Inner cone of main shaft directly mounted with elastic collect chuck in order to ensure the rotation precision
4.Drive part of machine tool use Taiwan HIWIN/PMI high precision P3 class ball bearing screw
5.Machine use Taiwan SYNTEC system,Japan Yaskawa servo motor control
6.Machine adopt roller guide rail structure,can affordlarger cutting and resistance to impact
7.The machine can be used for processing single head or multi-head worm.Widely use in the machining of motor drive shaft of smart home appliances and automobile electric lifting
8.Cutter shaft can realize large Angle rotation
| Model | Whirlwind Milling Machine DS-25W |
| Max.processing length(mm) | 250 |
| Max.processing modulus (m) | 1.5 |
| Tailstock function | optional |
| Knife guide bush | have |
| Spindle Max.speed(r/min) | 1500 |
| Spindle motor power(kw) | 4.4 |
| Spindle bore(mm) | Ф32 |
| Milling type | Internal rotation/outward rotation (outward rotation with tail stock) |
| Tool shaft Max.speed(r/min) | 6000 |
| Tool shaft motor power(kw) | 1.8/4.0 |
| Tool from | Forming tool |
| Max.installed tool quantity(qty) | 1 |
| System Min.resolution(mm) | 0.001 |
| X/Z axis travel(mm) | 100/250 |
| X/Z axis fast moving speed (r/min) | 12 |
| X/Z axis repeatability(mm) | ±0.003 |
| X/Z axis motor power(kw) | 1.3 |
| Machine power(kw) | 10 |
| Net weight(kg) | 2300 |
| Machine dimensions(L×W×H)(mm) | 2100×1550×1800 |
