1.The base of machine tool is integrally cast with resin sand , its features strong shock vibration resistance and less deformation.Ensuring the high rigidity and high precision of the machine tool. Widely applied in processing of long axis components for electronics, telecommunication, facsimile machine and printer etc
2.The machine tool control system use Taiwan SYNTEC system(other brand systems can be chosen)
3.Renowned electric appliances such as Yaskawa driver, servo motor and inverter as well as other world famous brands are used
4.Drive part of machine tool use Taiwan famous brand HIWIN/PMI high precision P3 class ball bearing screw and high speed linear slide rail
5.Automatic intermittent lubricating system is used, with intermission time controllable by the system
Model | DS-20Z |
Max.swing diameter(mm) | ¢20 |
Max.operating speed(rpm) | 8000 |
Spindle speed(r/min) | 8000 |
Spindle travel (mm) | 75 |
Min.dicisions(°) | Stepless |
Gang type quantity(row) | 5 |
Diameter of spindle(mm) | ¢22 |
Max.drilling diameter front(mm) | ¢7 |
Max.tapping diameter front(mm) | M6 |
Radial power tools quantity(row) | 4 |
Radial power tools max.speed(rpm) | 5000 |
Max.drilling diameter radial(mm) | 30 |
Max.tapping diameter radial(mm) | M6 |
Max.saw blade milling cutter diameter radial(mm) | 30 |
Coolant tank capacity(L) | 100 |
Middle of spindle to ground height(mm) | 1050 |
Machine power(kw) | 7 |
Net weight(kg) | 1780 |
Machine dimensions(L×W×H)(mm) | 1750×910×1700 |
