1.Machine tool control system uses Taiwan SYNTEC system. Other brand control system can be chosen
2.Machine tool is two-Axis CNC Inside Shuttle Grinder, which can grinding the large hole inside the workpiece, inner cone hole, inner cone face, outer end face and inner hole grinding cycle automatically
3.Machine tool bed is cast , the deformation is small, the rigidity is good
4.All the moving guide rail of machine tool adopts high precision rolling linear guide and sliding property, and high precision ball screw rod is used in feed reciprocating
5.Grinding machine adopts single grinding head design and double grinding head design
6.The machine tool sand wheel shaft adopts high speed electric spindle, which is controlled by static frequency converter and realizes the stepless speed regulation
7.The spindle flange can be installed directly set core hydraulic chuck Ф 160 three jaw
| Model | CNC36SG-I |
| Max.sewing diameter(mm) | 310 |
| Max.cutting length(mm) | 200 |
| Chuck size(inch) | 5″ |
| Spindle speed(r/min) | 45-4500 |
| Spindle power(kw) | 3.7 |
| Spindle bore(mm) | Ф46 |
| Spindle nose(mm) | A2-4 |
| Grinding head size(inch) | Ф100 outer diameter |
| Grinding head Max. speed(r/min) | 60000 |
| Grinding head quantity(qty) | 1 |
| Minimum resolution(mm) | 0.001 |
| X/Z axis travel(mm) | 340/250 |
| X/Z axis fast moving speed(r/min) | 24 |
| X/Z axis repeatability(mm) | ±0.003 |
| Taper(mm) | ≤0.003/100 |
| Circle processing precision(mm) | ≤0.003 |
| Blade replacement way | random |
| Machine power(kw) | 12 |
| Net weight(kg) | 2300 |
| Machine dimensions(L×W×H)(mm) | 2090×1430×1555 |
